The Schulte FX-318 is an 18-foot flex-wing rotary cutter designed for heavy duty mowing and land management. It’s built to handle tough jobs like mowing crop residue, pastures, weeds, orchards, and roadsides with reliable performance.
The Schulte FX-318 is an 18-foot flex-wing rotary cutter designed for heavy duty mowing and land management. It’s built to handle tough jobs like mowing crop residue, pastures, weeds, orchards, and roadsides with reliable performance.
18′ cutting width gives wide coverage, while an ultra-narrow transport width makes hauling and road travel safer and easier.
Heavy-duty construction with a 7 gauge domed deck that sheds water and debris for easier cleaning and longer life.
Power options: Works with either 540 rpm or 1000 rpm PTO, available in constant-velocity (CV) or equal-angle drives to match tractor setups.
Durability: Robust gearboxes, drive system, spun-formed stump jumpers, and heavy-duty hubs/spindles for long service life and stable operation.
Versatile cutting: Adjustable cutting height from about 1.75″ up to 16.75″, with roughly 3.5″ cutting capacity and good ground clearance for rough terrain.
Cutting Width 216” (5.5m)
Overall Width 228” (5.8m)
Overall Length 208” (5.3m)
Transport Width 86” (2.2m)(Singles on wings) 96” (2.4m) (Duals on wings)
Transport Height 109” (2.77m)
Deck Thickness 7GA (3/16", 4.6mm)
Weight 5800 lbs (2631kg) (Depends on configuration)
Hitch Weight 2350 lbs (1066kg)(Depends on configuration)
Minimum Tractor HP 75HP (56kW)
Recommended Tractor HP 90HP (67kW)
Tractor PTO Speed 540 or 1000rpm
Cutting Height 1.75" to 16.75" (44.5mm to 425mm)
Ground Clearance 14.75" (42.5mm)
Cutting Capacity 3.5" (89mm)
Blade Overlap 6" (152mm)
Divider Gearbox Rating 260HP (194kw)
Center & Wing Gearbox Rating 225hp (168kw) *
Output Shaft 2.38" (60.3mm)
Blade Tip Speed 540 rpm
Center 15980 ft/min (4871m/min)
Wing 16319 ft/min (4974m/min)
Blade Tip Speed 1000 rpm
Center 15974 ft/min (4869m/min)
Wing 16581 ft/min (5054m/min)
Wing Working Range 25 degrees down to 80 degrees up
Wing Floating Range 25 degrees down to 30 degrees up
Drive Size Main Cat.5CV (1000rpm), European Size 6 / Cat.6CV (540 rpm), European Size 8
Drive Size Center & Wings Category 6
Side Skirt Depth & Thickness 13.63" (346mm) .25" thick (6.35mm)
Suspension Rubber 3 puck grommet
